“C” Series
Product Details
The “C” Series dump pumps are designed to meet the tough demands of the dump trucking industry. Operating at 1800 RPM/2000 PSI, they provide reliable, consistent flow for a wide range of hydraulic applications. Rugged, efficient, and built to last, the “C” Series is a dependable choice for heavy-duty performance.
COMMON APPLICATIONS:
- Dump Trucks
- Dump Trailers
KEY FEATURES:
- Pressure to 2500 PSI
- Speeds to 2400 RPM
- 39 & 48 GPM @ 1800 RPM
- 2- or 3-line installations
- Relief valve protects pumps and cylinders
- Choice of mountings
- Air remote operators available
SPECIFICATIONS:
- Maximum Pressure (PSI): 2500
- 7/8-13 Tooth
| Part Number | Description | Shaft/b> | Gear | Inlet | Pressure & Return Port |
| HC102-LMS-20 | LH rotation, manual shift | 7/8"-13 Tooth | 2" | 1-1/4"NPT | 1" NPT |
| HC102-LMS-25 | LH rotation, manual shift | 7/8"-13 Tooth | 2.5" | 1-1/4"NPT | 1" NPT |
| HC102-LAS-25 | LH rotation, air shift | 7/8"-13 Tooth | 2.5" | 1-1/4"NPT | 1" NPT |
| HC102-RMS-25 | RH rotation, manual shift | 7/8"-13 Tooth | 2.5" | 1-1/4"NPT | 1" NPT |
| HC102-RAS-25 | RH rotation, air shift | 7/8"-13 Tooth | 2.5" | 1-1/4"NPT | 1" NPT |
| HC102-LAS-2598 | LH rotation, air shift | 1"-15 Tooth | 2.5" | 1-1/4"NPT | 1" NPT |
| HC102-RAS-2598 | RH rotation, air shift | 1"-15 Tooth | 2.5" | 1-1/4"NPT | 1" NPT |
| HC101-XMS-20 | Bi-rotational, manual shift | 1" Keyed | 2" | 1-1/4"NPT | 1" NPT |
| HC101-XMS-25 | Bi-rotational, manual shift | 1" Keyed | 2.5" | 1-1/4"NPT | 1" NPT |
| Part Number | Description |
| AKC102-4 | C101/C102, air shift kit, 4 bolt pattern |
| HM314-0100-005 | Mounting bracket |
| HMDPC-10 | 10-ft push/pull cable |
